This assumption was wrong, and destroyed a pretty expensive USB 3.2 cableto check the GPS UART lines (SBU1 & SBU2 ?).
GPS UART is connected to one of the SuperSpeed differential pairs
(i see NMEA@9600 TX sent by the bracket on USB-C pin '10' and assume RX on pin '11').
Code:
$PMTKEZ,16,6,0,6,0,0,0,0,6,0,6,0,0,0,6,0,6,0,6,0,0,6,6,6,0,6,6,6,0,6,0,6,6,*1A
$GNGGA,185253.000,48XX.XXXX,N,011YY.YYYY,E,2,9,0.92,611.8,M,47.7,M,,*41
$GPGSA,A,3,10,27,32,03,14,21,01,22,08,,,,1.24,0.92,0.84*0B
$BDGSA,A,3,,,,,,,,,,,,,1.24,0.92,0.84*13
$GPGSV,3,1,12,08,71,198,26,21,64,297,33,01,40,285,12,22,39,228,20*76
$GPGSV,3,2,12,27,39,155,29,32,39,100,20,10,33,054,24,36,31,153,29*7B
$GPGSV,3,3,12,14,18,315,16,28,15,323,,03,12,226,23,23,02,051,*7A
$BDGSV,1,1,00*68
$GNRMC,185253.000,A,48XX.XXXX,N,011YY.YYYY,E,0.76,128.52,180421,,,D*7E
$GNVTG,128.52,T,,M,0.76,N,1.41,K,D*2F
