VIOFO A149 Pro 2CH - Testing/Review - RCG

[rcg530]

Click on thumbnail image to see full size image

The VIOFO A149 Pro Duo 2CH dash camera is an update to the older A129 series dash camera. The A149 Pro offers the same general features as the A329S series of dash cameras.

• Specifications
  • Model Options
    • 2-Channel
      • A149 Pro 2CH : 4K Front + 1080p Rear
  • Cameras / Lens
    • Front
      • Sony STARVIS 2 IMX678 8MP
      • F1.8 Aperture, FOV=140°
    • Rear – RE100
      • Sony STARVIS 2 IMX662 2MP
      • F1.4 Aperture, FOV=136°
  • Fast Boot
    • System setting [On/Off] that enables a reduced boot time [Fast Boot]
      • This changes the boot time from a fully powered off state [not parking mode related].
      • Test Results
        • On – 2CH Boot Time = 3 seconds
        • Off – 2CH Boot Time = 11.5 seconds
  • HDR
    • Front / Rear
      • Supported
  • Wi-Fi
    • Wi-Fi 6 (2.4 GHz & 5 GHz) / 2.4 GHz / 5 GHz
  • GPS
    • Quad-mode satellite coverage (GPS, BeiDou, Galileo, and GLONASS)
  • Status LEDs
    • The status LEDs from older models are now presented as backlighting to the A149 Pro's buttons.
  • Voice Commands
    • Voice commands are available
  • Camera Connections
    • Rear camera connects to the front camera using USB-C cable
  • CPL
    • Front: CPL-800 Included
    • Rear: CPL-600 (Optional)
  • Parking Modes
    • Hybrid
    • Low Power Impact Detection [LPID]
    • Standard [Auto Event Detection, Time-Lapse, Low Bitrate]
    • Vehicle Battery Protection
      • Timer Cut-Off
      • Voltage Cut-Off
      • Battery Pack Percentage Cut-Off
    • Geofencing GPS Zones – Optional Feature
      • Turns off or enters LPID parking mode when parked in one of the three available parking zones
    • Requires HK6-A or HK4 hardwire kit



[rcg530]

A149 Pro Duo - Power Consumption Tests

My tests were performed with a pre-production unit and an early firmware version.

Click on thumbnail image to see full size image



[rcg530]

Reserved for future use



[Hack_man]

Does it seem odd that it uses the IMX662 2MP for the rear camera and not IMX675 5MP?
The IMX662 specs look more suitable for a low light/interior cabin camera.



[Chuck McCoy]

The VIOFO A149 Pro Duo 2CH dash camera is an update to the older A129 series dash camera. The A149 Pro offers the same general features as the A329S series of dash cameras.

This looks like a nice improvement / replacement for the original A129 Pro Duo (2019).
So far I'm not liking;
a.) 1080p Rear Camera
b.) Type-C Rear Camera Cable
I would have preferred;
a.) 2K (IMX675) Rear Camera
b.) MMCX Coax Rear Camera Cable
I'm thinking these 2 choices are to keep MSRP "budget friendly", so I'm OK with that.

FastBoot sounds exciting, can't wait to test that.
Wow, that new GPS Mount looks THICK.

1.) Why do we have a new HK6-A Hardwire Cable?
2.) What the difference between HK6, and HK6-A?
3.) When is the official release date for Amazon USA?



[rcg530]

a.) 1080p Rear Camera

My guess is that if a 2K rear camera was offered, it would directly compete with the A229 series.

b.) Type-C Rear Camera Cable

I'm also not a fan of thick USB-C cables.

Wow, that new GPS Mount looks THICK.

The GPS mount is fixed [non-removable]. There's a thin plastic mounting plate for the windshield that the fixed GPS mount attaches to.

1.) Why do we have a new HK6-A Hardwire Cable?

I was not aware of a "-A" version until it was mentioned in the VIOFO listing page. The A149 Pro user manual still lists the HK6 and the HK4 as an optional accessory.

2.) What the difference between HK6, and HK6-A?

There's also a HK6-F version [listed on T330/T340 pages]. The HK6-A has a straight USB-C connector for the camera connection end. The HK6-F has a 90-degree USB-C connector for the camera connection end. I'm not sure if there's any addition difference beyond the connector type.

3.) When is the official release date for Amazon USA?

I have no idea of the release date on Amazon US.



[Chuck McCoy]

My guess is that if a 2K rear camera was offered, it would directly compete with the A229 series.

Correct.

I'm also not a fan of thick USB-C cables.

It's not so much the thickness that bothers me.
It's the lack of modularity.
How many times have we seen a customer ask; "Is this "USB Type-C" from Amazon going to work, because I need a longer / shorter one?"
Then we go down the rabbit hole of of proprietary "PINS" in a Type-C Cable, (what a nightmare).
MMCX Coax is just a simple thing of beauty.
But I understand it has a significant cost increase.

The GPS mount is fixed [non-removable]. There's a thin plastic mounting plate for the windshield that the fixed GPS mount attaches to.

Well, well, well, I've been asking for truly "built-in" GPS modules since A129 Pro (2019).
I guess we finally got it, (yes I know T130 had it) 🤣

Thanks for all the answers.



[rcg530]

I added my power consumption test results to post #2 of this thread.



[indigo]

what different the front camera of 119mpro and 149produo



[rcg530]

what different the front camera of 119mpro and 149produo

Not much. They both use the Sony STARVIS 2 IMX678 image sensor. The A119M Pro creates 61.4 Mbps front video footage [bitrate = high]. The A149 Pro Duo front creates 58.1 Mbps front video footage [bitrate = maximum]. The A149 Pro creates 1080p rear video footage at 15.6 Mbps. Both front lenses have a F1.8 aperture and a FOV of 140°.

The A149 Pro does have the advanced parking modes [like the A329S series]. The A119M Pro was rumored to get those advanced parking modes at some point with a firmware update, but that has not occurred yet.



[Augustus]

The VIOFO A149 Pro Duo 2CH dash camera is an update to the older A129 series dash camera. The A149 Pro offers the same general features as the A329S series of dash cameras.

• Specifications
  • Model Options
    • 2-Channel
      • A149 Pro 2CH : 4K Front + 1080p Rear
  • Cameras / Lens
    • Front
      • Sony STARVIS 2 IMX678 8MP
      • F1.8 Aperture, FOV=140°
    • Rear – RE100
      • Sony STARVIS 2 IMX662 2MP
      • F1.4 Aperture, FOV=136°
  • Fast Boot
    • System setting [On/Off] that enables a reduced boot time [Fast Boot]
      • Test Results
        • On – 2CH Boot Time = 3 seconds
        • Off – 2CH Boot Time = 11.5 seconds
  • HDR
    • Front / Rear
      • Supported
  • Wi-Fi
    • Wi-Fi 6 (2.4 GHz & 5 GHz) / 2.4 GHz / 5 GHz
  • GPS
    • Quad-mode satellite coverage (GPS, BeiDou, Galileo, and GLONASS)
  • Status LEDs
    • The status LEDs from older models are now presented as backlighting to the A149 Pro's buttons.
  • Voice Commands
    • Voice commands are available
  • Camera Connections
    • Rear camera connects to the front camera using USB-C cable
  • CPL
    • Front: CPL-800 Included
    • Rear: CPL-600 (Optional)
  • Parking Modes
    • Hybrid
    • Low Power Impact Detection [LPID]
    • Standard [Auto Event Detection, Time-Lapse, Low Bitrate]
    • Vehicle Battery Protection
      • Timer Cut-Off
      • Voltage Cut-Off
      • Battery Pack Percentage Cut-Off
    • Geofencing GPS Zones – Optional Feature
      • Turns off or enters LPID parking mode when parked in one of the three available parking zones
    • Requires HK6-A or HK4 hardwire kit

Click on thumbnail image to see full size image
View attachment 93961View attachment 93967View attachment 93968View attachment 93964View attachment 93965

Do we have information on what particular Novatek chipset is in this camera?. Seems to be the new trend with these cameras and Vantrue, having fast startups.



[TonyM]

Fast Boot

• System setting [On/Off] that enables a reduced boot time [Fast Boot]
  • Test Results
    • On – 2CH Boot Time = 3 seconds
    • Off – 2CH Boot Time = 11.5 seconds

Is it only the A149 Pro that has this fast boot option? (i.e. it's not mentioned for the T330/340)

Is there a downside to using it, such as standby power consumption?



[Augustus]

Is it only the A149 Pro that has this fast boot option? (i.e. it's not mentioned for the T330/340)

Is there a downside to using it, such as standby power consumption?

I would wonder if the bitrate is dropped with the fastboot videos. That is what is happening with a competitors product I am testing at the moment that also has fast boot.



[rcg530]

Is it only the A149 Pro that has this fast boot option? (i.e. it's not mentioned for the T330/340)

Is there a downside to using it, such as standby power consumption?

This feature is present only in the A149 Pro, not the T330/T340. The "fast boot" is from a powered off state only, not part of the LPID parking mode functionality. LPID parking mode response to an impact is about 1.5 seconds.



[rcg530]

With the release of the A149 Pro, T330, and T340 dash camera models, VIOFO stated that the A149 Pro should use the HK6-A hardwire and the T330/T340 models should use the HK6-F hardwire kit.

All three dash camera models can be powered by the older HK4 hardwire kit, the HK6, or the two new HK6 variants [HK6-A, HK6-F].

You can still use a HK4 hardwire kit to power the dash camera, but you'll miss out on the HK6 added features. When you use a HK4 hardwire kit, you miss out on the "Cut-Off Voltage" battery protection feature and the ability to display the vehicle's voltage level in the video's "Stamp" [status line]. That's true for all models that include those new features [A329S series, A119M Pro, A149 Pro, T330, T340].

The only difference between the HK6, HK6-A, and HK6-F hardwire kits is the USB-C connector that plugs into the dash camera.

I outline the differences in this other thread.

Thread 'VIOFO HK6 / HK6-A / HK6-F Hardwire Kits - What's The Difference'

Sep 16, 2026

With the release of the A149 Pro, T330, and T340 dash camera models on 15-Sep-2026, VIOFO included references to two new HK6 hardwire kit variants [HK6-A, HK6-F].

The only difference between the original HK6 and the two new variants is the connector on the end of the cable that plugs into the dash camera.

The original HK6 has a 90-degree USB-C connector, but so does the HK6-F. The difference being that the HK6-F has a shorter/slimmer USB-C connector end making it more appropriate for use with the T330/T340 dash cameras when the tamper-resistant cover is used with the T330/T340.

The...

• rcg530
• Replies: 2
• Forum: VIOFO Other

•



[65536]

Thanks for sharing.



[rcg530]

Here are three rear camera frame grabs from a VIOFO A149 Pro FHD rear, a VIOFO T330 QHD rear, and a VUEROiD S1-4K QHD rear. All three have HDR enabled for the rear camera.

Click on thumbnail image to see full size image:
