YiMAX-PRO script.

Kaouthia

New Member
Joined
Jul 8, 2016
Messages
14
Reaction score
8
Country
United Kingdom
Dash Cam
Yi HDs
Went out today to do some testing, so here's a quick comparison.

The stock Yi is on the left, with YiMAX on the right (1920x1080, 24fps, 50mbps). There's a lot of aliasing and halos in fine details on the stock Yi, although YouTube's compression seems to reduce the issue a little compared to the original file. No problem with YiMAX.


Yes, I did feel like an idiot walking around with this all day. :D


Last edited:

xantrk

New Member
Joined
Oct 4, 2015
Messages
8
Reaction score
1
Country
Turkey
It makes my Yi reboot , while trying to take a couple of pictures repatedly. Any ideas why it might be happening? I though maybe my sd card was not fast enough to handle raw files, deleted the raw line. It is better but still reboots after 5-6 images.

Edit: Plus, some of the images have quite yellow tint than previous ones. Really yellow a lot.

OP
nutsey

nutsey

Active Member
Joined
May 12, 2015
Messages
395
Reaction score
202
Location
Russia
Country
Turkey
It makes my Yi reboot , while trying to take a couple of pictures repatedly. Any ideas why it might be happening?
Yes. YiMAX-PRO script is for video, not photo.


xantrk

New Member
Joined
Oct 4, 2015
Messages
8
Reaction score
1
Country
Turkey
Yes. YiMAX-PRO script is for video, not photo.
Oh, it makes sense. Thanks for the answer. I thought the comparison images are actually images. Did not realised they are snaps from videos. Thanks again!


vili

Member
Joined
Oct 20, 2015
Messages
66
Reaction score
0
Country
Austria
Yes, its sharper, but at the same time more noise at darker parts of the image.
Would be good this watercolor effect only at dark parts of the frame, and no effect where the light is enough :)

Does this script improve 1080/60 quality too?
Can somebody make a compare test in this mode? 30p is much much better, but i read 1080/60p
is an upscale from 720p, so sharpness will never be as good as with gopro3.

thx!


vili

Member
Joined
Oct 20, 2015
Messages
66
Reaction score
0
Country
Austria
Thx but currently i don't have my yi's in my hand.
Anybody can test it?


Tanckom

Active Member
Joined
May 1, 2016
Messages
179
Reaction score
61
Country
Germany
Hey nutsey, one question. I found out that the bug of XIMODE by splitting the files is related to the resolution settings.
By applying your resolutions settings of Yimax-pro to all the other scripts:
Code:
writeb 0xC06CC426 0x02
writeb 0xC05C1EAC 0x05
writew 0xC05C1EB2 0x4220
writel 0xC05C1EB4 0x3f400000
writel 0xC05C1EB8 0x3fa00000
The file splitting dissapeared.
I know what the writew 0xC05C1EB2 0x4220 is for applying 40Mbits.
But what are the others for? And where can i find a documentation about it? If there is none, can you share your documentation/sources about it?

Thanks for your help!


Németh Szilárd

New Member
Joined
Dec 18, 2015
Messages
1
Reaction score
0
Country
Hungary
Hi!
Is there a 2.5K version of this script? If not how can I make it or what should i change in the files?

OP
nutsey

nutsey

Active Member
Joined
May 12, 2015
Messages
395
Reaction score
202
Location
Russia
Country
Turkey
I found out that the bug of XIMODE by splitting the files
What do you mean for "splitting files"? Recording a short one and then another one with lower bitrate?

But what are the others for?
Those are exactly like I described in comments for the script:
"#Set 1296p30 video mode,
ABR,
40Mbps,
.75 -
1.25 bitrate range:"

And where can i find a documentation about it? If there is none, can you share your documentation/sources about it?
There are no specific docs at the moment yet. I'm not getting any profit from Xiaomi Yi studies, so maybe I will post all of my research results one day.


Tanckom

Active Member
Joined
May 1, 2016
Messages
179
Reaction score
61
Country
Germany
The videos are somehow splitting after several seconds and the second video has 26Mbits.
what do you mean with
ABR
.75-
1.25 bitrate range?
(Still need to learn a lot of things ;) )

Yeah, know the drill, but thanks for your work!


Tanckom

Active Member
Joined
May 1, 2016
Messages
179
Reaction score
61
Country
Germany
writeb 0xC06CC426 0x02 - this one sets 1296p30
writeb 0xC05C1EAC 0x05 - this one sets CBR2 bitrate mode (it works like ABR so I called it so in the script)
writew 0xC05C1EB2 0x4220 - 40 Mbps
writel 0xC05C1EB4 0x3f400000 - low bitrate limit for ABR
writel 0xC05C1EB8 0x3fa00000 - high bitrate limit for ABR
By your explanation in my thread, does that mean the CBR2 and ABR compression does apply generally for every video mode, or only for this 1296p30 one?
Because I want to apply those compressions with using only the bitrate commands and the compression. So the user still has the ability to change resolution...
F.ex., would this work?

Code:
#+++++++++ BITRATE AND RESOLUTION ++++++++++

#2304x1296p30     35Mbit
writew 0xC05C1EB2 0x420C

#1080p60         35Mbit
writew 0xC05C1EE2 0x420C

#1080p48         35Mbit
writew 0xC05C2452 0x420C

#1080p30         35Mbit
writew 0xC05C1F72 0x420C

#1080p24         35Mbit
writew 0xC05C2492 0x420C

#1200p60        35Mbit
writew 0xC05C2092 0x420C

#720p120         35Mbit
writew 0xC05C2812 0x41F0

#- low bitrate limit for ABR
writel 0xC05C1EB4 0x3f400000
# - high bitrate limit for ABR
writel 0xC05C1EB8 0x3fa00000
#- this one sets CBR2 bitrate mode (it works like ABR so I called it so in the script)
writeb 0xC05C1EAC 0x05

OP
nutsey

nutsey

Active Member
Joined
May 12, 2015
Messages
395
Reaction score
202
Location
Russia
Country
Turkey
Each bitrate mode value is linked to certain resolution. Use appropriate offset shift for any of them.


Tanckom

Active Member
Joined
May 1, 2016
Messages
179
Reaction score
61
Country
Germany
Okay, would this be correct? Or how do you continue?

Code:
#+++++++++ BITRATE AND RESOLUTION ++++++++++

#2304x1296p30     35Mbit
writew 0xC05C1EB2 0x420C
writel 0xC05C1EB4 0x3f400000
writel 0xC05C1EB8 0x3fa00000
writeb 0xC05C1EAC 0x05

#1080p60         35Mbit
writew 0xC05C1EE2 0x420C
writel 0xC05C1EE4 0x3f400000
writel 0xC05C1EE8 0x3fa00000
writeb 0xC05C1EEC 0x05

#1080p48         35Mbit
writew 0xC05C2452 0x420C
writel 0xC05C2454 0x3f400000
writel 0xC05C2458 0x3fa00000
writeb 0xC05C245C 0x05
...

OP
nutsey

nutsey

Active Member
Joined
May 12, 2015
Messages
395
Reaction score
202
Location
Russia
Country
Turkey
writeb 0xC05C1EDC 0x05

for 1080p60


Tanckom

Active Member
Joined
May 1, 2016
Messages
179
Reaction score
61
Country
Germany
Where can I find those for writeb?


drawsko

New Member
Joined
Jul 29, 2016
Messages
1
Reaction score
0
Country
Poland
Great job :)

#Set 1080p60 video mode, ABR, 40Mbps, .75 - 1.25 bitrate range:
writeb 0xC06CC426 0x03
writeb 0xC05C1EDC 0x05
writew 0xC05C1EE2 0x4220
writel 0xC05C1EE4 0x3f400000
writel 0xC05C1EE8 0x3fa00000

Please settings for:
- 1080p30 40Mbps
- 1080p30 35Mbps


z0ska

New Member
Joined
Jul 14, 2015
Messages
8
Reaction score
1
Country
Poland
The script is great but the beep sound is to low for me. I dont know when the cam is ready ;)
Is there any option to increse the volume of the beep?
